60MPa hydraulic oil press machine mini oil milling machinery for
sale
Operating priciple of hydraulic oil press machine:
The working principle is that the when the oil material is put into the assembly of the press boring,
then it being driven up by the oil cylinder piston, oil will be
outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil
storage.
Oil Press Machine Information
The design is scientific, the structure is reasonable, the
operation is simple, the safety is stable, and the fully automated
device is used. It takes only a few minutes from the feeding to the
finished product.
Our oil press has many advantages, as follows:
1. High oil yield, 30% higher oil yield than old equipment, and
considerable economic net profit.
2. Labor saving, the same output can save labor, one to two people
can produce.
3. Use Wide: multi-purpose machine, can squeeze more than 30 kinds
of oil crops such as peanut, flax, sesame, rapeseed, oil sunflower,
cottonseed, soybean, etc.,
multi-stage pressing, one-time pressing, pure oil--vacuum
filtration residue, guarantee oil purity , in line with health and
quarantine standards.
4. Small footprint: oil square needs 10-20 square meters to meet
the use.
5. Innovative concept, mechanical and electrical integration.
Advantages:
(1) High oil yield, pure oil, no filtration.
(2) The oil is squeezed once, the speed is fast, and the labor
intensity is small.
(3) Electromechanical integrated design, small footprint and easy
operation.
(4) Fast purification, stable and durable performance.
(5) Professional manufacturer.
Seeds application of hydraulic oil making machine:
Our machine can press many different oil material, like sesame,
sunflower seeds, olive, avocado and etc.
If you want to process other special raw material, please cantact
us to ensure.
Technical parameters of 6YY-185
Other models can meet your capacity demands.
| Model | 6YY-250 | 6YY-270 | 6YY-300 | 6YY-335 |
| Weight | 1060kg | 1230kg | 1600kg | 1750kg |
| vacuum Power | 1.1kw | 2.2kw | 2.2kw | 2.2kw |
| 3phase | 2.2kw | 4.0kw | 4.8kw | 4.8kw |
| Working pressure | 60MPa | 60MPa | 60MPa | 60MPa |
| Capacity (Kg/h) | 11kg/batch | 13.5kg/batch | 16kg/batch | 20kg/batch |
| Dimension(mm) | 710*950*1560 | 750*1010*1640 | 1000*1100*1660 | 1100*1240*1730 |
Show details
All the goods will be inspected by our own quality inspection
department, through the advanced machine to make sure no problem.
Packing and shipping
We use strong wooden case to ensure the safety of your goods in
transit.
Our service
1.Professional engineer
Our professional engineer will test the machine in each step.
2.Specialist manufacture
Every machine carefully adjusted before shipment.
3.After-service
The equipment guarantee period is one year, During guarantee
period, the seller will provide maintenance free service.(Except
the breakdown and destroy caused by person and force majeure)
Company information
Since1998, Henan Lewin Industry Development Co., Ltd was found
officially registered under Henan Companies Registry.It is a firm
which has the ability for Manufacture,Research&Development,
Sale and Export. Our mainproducts are hydraulic oil press machine, spiral
oil press machine, the accessory equipment for the oil press
machine and other machine.
